Upgraded cooling systems are not just for off-road rigs and big haulers. Even basic mods/upgrades like oversized tires can increase strain on your engine in adverse conditions. The CSF Radiator provides extra protection that: Extends engine life by maintaining optimal coolant temperatures. Improves towing capacity by enhancing cooling efficiency. Eliminates performance limitations during demanding driving conditions. Provides peace of mind with superior construction and durability
When engine coolant overheats, performance suffers and you are forced to stop driving or risk a cooling system failure. CSF & Full-Race engineers identified this vulnerability during extensive real-world testing of F-150 and Raptor models under demanding conditions. Having to stop and wait for your engine to cool down is more than just an inconvenience, it is a limitation that shouldn't exist in modern trucks. Especially not a Raptor.
An upgraded radiator helps eliminate the concern of overheating. These advanced designs feature larger 2-Row, 42mm aluminum cores which increase the fluid capacity of the radiators, and greatly improves heat dissipation. CSF's Exclusive B-Tube Technology increases the heat transfer by approximately 15% over regular oval welded tubes. In addition, the ultra-efficient multi-louvered fins maximize airflow through the core for the best possible performance. The result is a dramatic temperature reduction under all driving conditions.
Ford definitely learned some lessons from previous generations and gave some 14th Generation F-150s / 3rd Gen Raptors a pretty decent radiator. While the factory system seems to cope with modifications better than previous generations, more people are pushing these new rigs harder than ever. Bigger turbos, more boost, heavier accessories, etc, all increase heat output of the motor.
Instead of waiting for your factory radiator to fail or putting up with power loss due to high engine temps, you can get ahead of the problem with the CSF Radiator. Upgrading to the CSF Radiator offers a lot of advantages including: 50% larger core volume than the factory radiator. 20-25% increase in heat transfer efficiency using CSF's exclusive 5mm Fin Technology. 100% TIG welded Aluminum construction (compared to plastic end tanks crimped). Perfect for daily driving, towing, and off-road adventures.
Features
- 2-Row - 42mm Ultra-High-Performance Core
- Cooling Tubes with CSF's Exclusive B-Tube Technology
- New 5mm Tall Ultra Efficient Fins with a Multi-Louvered Design for Maximum Surface Area Contact
- CNC Machined Mounting Pins and Brackets
- OEM Style Inlet/Outlet
- 100% All Aluminum TIG-Welded Construction
- True Plug-and-Play "Drop-in Fit" Installation Requires Absolutely No Modifications
- Individually Leak and Pressure Tested
- 2-Year Limited Warranty
Applications
| Year Range |
Make |
Chassis Code |
Model |
Trim |
Engine / Trans / Etc |
Notes |
| 2022-2024 |
Ford |
U324 |
Expedition |
- |
Turbocharged 3.5L V6 |
- |
| 2022-2024 |
Lincoln |
- |
Navigator |
- |
Turbocharged 3.5L V6 |
- |
| 2021-2025 |
Ford |
P702 |
F-150 |
Raptor |
Turbocharged 3.5L V6 |
- |
| 2023-2026 |
Ford |
P702 |
F-150 |
Raptor |
Supercharged 5.2L V8 |
- |
| 2021-2026 |
Ford |
P702 |
F-150 |
Police Responder |
Turbocharged 3.5L V6 |
- |
| 2021-2026 |
Ford |
P702 |
F-150 |
- |
Turbocharged FULL HYBRID EV-GAS (FHEV) 3.5L V6 |
- |
OEM Part Numbers
- Ford: ML3Z-8005-B
- Ford: ML3Z 8005 B
- Ford: ML3Z8005B
Warranty
Cooling Systems and Flexibles, Inc. (CSF) warrants CSF’s High-Performance Cooling Systems, under normal use and service, to the original purchaser of the vehicle in which the product was originally installed. For more information and details please visit the CSF Warranty Page
SKU# 8303 Warranty Term: 2 years
